GS8304 LED Strip
Product Feature
1. It uses the GS8304 chip with a wide input voltage range and 16-bit precise control. When paired with an LED controller, it supports a driving speed up to 1200kHz. High refresh rate ensures smooth and high-frame-rate performance.
2. The chip comes in an SOP8/10 package. It has RGBW output pins and redundant data connections for more stable signal transmission and easier installation and maintenance.
3. It is an addressable RGBW LED strip. It contains up to 120 LEDs per meter and runs on a safe 24V low voltage.
4. It can be cut every 100mm. The length can be adjusted flexibly to meet different needs.
5. It is equipped with 3M self-adhesive backing for easy and secure installation.
6. The GS8304 supports digital current control for LEDs. Each color channel has 4-bit current adjustment. Brightness can be lowered without losing resolution. Each color’s current can be adjusted separately for more accurate color mixing. All settings can be configured through the controller.
GS8304 LED Strip Manufacturers & Suppliers
LEDSuntech focuses on GS8304 LED strip R&D and production. Each of our products is strictly tested before delivery. We do not conduct random inspections, all LED strips will be 100% quality tested.
Support OEM or ODM. Our high-quality GS8304 RGBW digital LED strip products have passed ISO:9001, CE, RoHS, FCC, UL, ETL and other certifications.
We strive to be a leader in the LED lighting industry with constantly breaking the boundaries of innovation and meeting the changing needs of our customers.
What is GS8304 LED Strip?
The GS8304 LED strip is a 24V addressable RGBW LED strip powered by the GS8304 driver chip. It features a high refresh rate as well as precise brightness and color adjustment capabilities; however, it does not support breakpoint resume functionality.
GS8304 RGBW LED strip is composed of internal control pattern 5050 packaged lamp beads. LED density specifications are 120 LEDs/meter.
It can be controlled by Arduino, Raspberry Pi, Fadecandy, K1000C, SP105E, SP107E, SP110E, etc. to achieve a variety of color changes.
GS8304 LED Strip Application
The GS8304 LED strip is suitable for dynamic full color lighting applications, such as stages, bars, architectural illumination, and advertising lightboxes, and can also be utilized in esports rooms, home theaters, and various creative lighting installations to deliver fluid, vibrant lighting effects.
Wholesale GS8304 LED Strip Series
Voltage: 24V
Power: 15 W/M
PCB Width: 10mm
LEDs density: 120 LEDs/m
Pixel Quantity: 10 pixels/m
Color: RGBW
Break Continue: No
Waterproof type: IP20
Suppose the parameters of the GS8305 LED strip above do not meet your needs. Then please contact our experienced team of engineers for customization.
FAQ
1) What is the capacity of your factory?
Answer: LED strip: more than 10000 meters per day;
Addressable digital LED strip: 2000-5000 meters per day;
Neon extrusion: 150-350 meters per hour.
2) What is the competitive advantage of your factory?
Answer: With 16 years of LED marketing experience and 10 years of experience in R&D team. Competitive products are SPI and DMX512 addressable digital LED strips.
Certification System
LEDSuntech has more than 1000 kinds of LED light strips. We want our customers to feel confident that their LED strips are safe and manufactured to the highest quality. In order to ensure the best performance of our LED light strip products, all products have been tested by third-party authoritative laboratories and have obtained multiple quality certifications including ISO:9001, CE, RoHS, FCC, UL, ETL, etc.
