IP65 LED Strip
Product Feature
(1) The IP65 LED strip’s silicone dripping process can protect the internal components from the external environment;
(2) IP65 LED light strips emit uniform light and have high color consistency;
(3) IP65 LED light strip flexibility: the silicone dripping process is soft and bendable, adapting to various decorative needs;
(4) IP65 LED light strip waterproof: It has waterproof properties and is suitable for indoor and outdoor decoration and lighting.
(5) IP65 LED light strip is easy to install: it can be fixed and installed through the adhesive or bracket on the back
(6) OEM or ODM mode of cooperation can be provided;
(7) Product life＞50000H.
IP Classification
IP protective lamp beads are marked with two numbers. The first letter represents the level of contact protection and foreign object protection. 6 represents: dust is sealed, and dust should not invade the box at a low pressure of 20 kbar; the second letter represents the waterproof protection level, and 5 represents protection against water jets. Water jets directed at the box from every direction will be protected. No damage should be caused.
What is IP65 LED Strip?
The IP65 LED strip adopts a production process of silicone dripping. A single-component silicone material + a proportion of curing agent is dripped on the surface of the lamp bead. After curing, the finished LED lamp strip can provide waterproof and dustproof protection elements. The function of the device.
IP65 LED Strip Application
- Interior decoration: used for decorative lighting in homes and commercial places, such as restaurants, bedrooms, showcases, etc.
- Commercial lighting: advertising light boxes, signs, etc. in shopping malls, hotels and other places.
- Stage effects: Landscape lighting effects for performance stages, nightclubs and other places.
Wholesale IP65 LED Strip Series
IP65 LED strips are a great choice for outdoor applications as well as indoor areas that may be exposed to water or dust. Although they are waterproof, it is important to note that these strips are not suitable for submersion in water, for example, IP65 strips are not suitable for use in swimming pools or water tanks.
LEDSuntech offers a variety of ip65 LED strips: DC12V IP65 LED Strip By Series, DC24V IP65 LED Strip By Series, AC220V AC110V IP65 LED Strip By Series.
PCB width: 5mm, 8mm, 10mm, 12mm.
LED Type: SMD2835, SMD3535, SMD5050.
Color: White, CCT, RGB, RGBW, RGBWW, RGBCCT.
LED density: 60leds/m, 96leds/m, 120leds/m, 140leds/m, 180leds/m, 192leds/m.
Waterproof type: IP65, suitable for indoor and outdoor applications.
Lighting angle: 120°
If the parameters you need are not listed above, our experienced team of engineers will help you customize an IP65 LED strip to meet your needs. Please contact us to discuss your lighting project.
IP65 LED Strip Classification
DC12V IP65 LED Strip By Series
SMD2835;
The number of LED lamp beads is 120 LEDs/m and 180 LEDs/m;
PCB width is available in 5mm/12mm;
Conventional color temperatures are 2700K, 3000K, 4000K, 5000K, and 6500K, but the color temperature can also be customized.
Specification Download
| Specification Name | Download |
|---|---|
| 2835-DC12V-120leds/m-5mm-CCT LED Strip Specification |
|
| 2835-DC12V-180leds/m-12mm-White LED Strip Specification |
|
DC24V IP65 LED Strip By Series
SMD2835; SMD3535; SMD5050;
LED density is 96leds/m, 120 LEDs/m, 140leds/m, 180 LEDs/m and 192leds/m;
PCB width is available in 8mm/10mm/12mm;
Conventional color temperatures are 2700K, 3000K, 4000K, 5000K, and 6500K, but the color temperature can also be customized.
Specification Download
| Specification Name | Download |
|---|---|
| 2835-DC24V-120leds/m-8mm-White LED Strip Specification |
|
| 2835-DC24V-140leds/m-10mm-CCT LED Strip Specification |
|
| 2835-DC24V-192leds/m-10mm-RGBWW LED Strip Specification |
|
| 3535-DC24V-120leds/m-8mm-RGB LED Strip Specification |
|
| 5050-DC24V-96leds/m-12mm-RGBW LED Strip Specification |
|
AC220V AC110V IP65 LED Strip By Series
Voltage: 110V/220V AC.
LED density is 60leds/m, 120 LEDs/m;
PCB width is available in 12mm;
Conventional color temperatures are 2700K, 3000K, 4000K, 5000K, and 6500K, but the color temperature can also be customized.
Specification Download
| Specification Name | Download |
|---|---|
| 2835-AC220V-60leds/m-12mm-White LED Strip Specification | |
| 2835-AC220V-120leds-12mm-White LED Strip Specification | |
Custom IP65 LED Strip Options
| LED Type: | SMD2835, SMD3535, SMD2216, SMD5050 | IP Rating: | IP20, IP54, IP65, IP66, IP67, IP68 |
|---|---|---|---|
| LED Density: | 60LEDs/m, 120LEDs/m, 132LEDs/m, 168LEDs/m, 180LEDs/m, 240LEDs/m | 3M Tape Type: | 9080A, 9948, 9495 |
| LED Brands: | EPISTAR chip, Osram, Philips | Length: | 5m/reel, 10m/reel, 20m/reel |
| Voltage: | 5V, 12V, 24V, 36V, 48V | PCB Width | 5mm, 6mm, 8mm, 10mm,12mm,15mm,20mm |
| Color: | White(1800K/2700K/3000K/4000K/5000K/6000K), CCT, RGB, RGBW,RGBWW,RGBCCT | Wire: | AWG18, AWG22 |
| Power: | 6W/m, 7.2W/m, 8W/m, 12W/m, 14W/m, 15W/m, 16W/m, 18W/m, 20W/m | Label: | ODM OEM customization |
IP65 LED Strip Manufacturers
LEDSuntech is China’s professional IP65 LED strip manufacturer. OEM or ODM are available. Our high-quality IP65V LED strip products have passed a series of certifications such as ISO:9001, CE, RoHS, FCC, UL, ETL, etc. We have undertaken private brand and OEM/ODM orders from over 30 countries in the US, Europe, Australia and Asia.
Light Up Your LED Project With LEDSuntech!
